PERT/PEX/PPR Pipe Extrusion Line
Description
PERT/PEX/PPR Pipe Extrusion Line Performance ＆ Advantages
Our high-efficiency single and double-strand extrusion lines for PPR/HDPE pipes are specially designed to match the properties of PP-R and HDPE materials. Equipped with our in-house developed JWS series high-efficiency single-screw extruders and SIEMENS PLC control system, these lines allow fully automatic operation from the main extruder to all downstream equipment. They deliver high output and stable, consistent extrusion performance.
- This line comes with a high-speed, high-output single-screw extruder, paired with professionally designed pipe dies specially optimized for PPR, PERT and PEX materials.
- The main screw adopts BM high-efficiency type, which boosts output while maintaining consistent wall thickness and a smooth pipe surface.
- Special mold for small pipes, water film type high-speed calibration sleeve, equipped with digital display flow adjustment device, small pipe molding is fast and the speed is high.
Efficient Cooling
Our cooling tank's main components, such as the box body and flanges, are widely made of SUS304 stainless steel to ensure corrosion resistance and a long service life. The nozzle is equipped with a quick - change connector, which facilitates quick cleaning and replacement. Our cooling tank equipped with an accurate water - temperature and water - level control system, it ensures the stability and consistency of the cooling process.
High-quality Gearbox
PPR Pipe Extrusion Line is equipped with high-torque precision gearboxes, the box body material is HT200, and is connected to an independent cooling circulation device externally.
Application
PERT pipe
PERT pipe is the standard choice for underfloor heating and radiator connections in residential and commercial buildings. It's also widely used for indoor hot and cold water plumbing, especially in high-rise apartments, and for fan coil unit connections in HVAC systems.
PEX pipe
Thanks to its higher temperature and pressure resistance, PEX pipe is typically found in demanding heating systems such as high-temperature radiator heating. You'll also see it in residential fire sprinkler systems, modern manifold-based plumbing layouts, and even outdoor snow-melt systems for driveways and walkways.
PPR pipe
PPR pipe remains the most common solution for building hot and cold water supply lines. Its clean, non-toxic properties also make it suitable for purified drinking water systems. In industry, it's frequently used for chemical and food fluid transport where operating temperatures are relatively moderate.
Specification
|
Model |
Pipe spec (mm) |
Extruder |
Main Power(kw) |
Output (kg/h) |
|
JWS-PPR-63(single) |
20-63 |
JWS 60/40 |
110 |
180~220 |
|
JWS-PERT-32(high speed) |
16-32 |
JWS 60/40 |
140 |
180~220 |
|
JWS-PERT-32(double) |
16-32 |
JWS 60/40 |
140 |
250~300 |
|
JWS-PE/PERT-63(double) |
20-63 |
JWS 60/40 |
140 |
250~300 |
Company Profile
Jwell was founded in 1997, China Plastics Machinery Industry Association vice president unit, plastic extrusion equipment, chemical fiber spinning complete sets of equipment manufacturers. The production bases of Jwell company cover approximately 1,000,000 square meters and consist of 11 domestic factories and 3 foreign factories. The company has 26 professional subsidiaries and three heat treatment nitriding plants. It has an annual output of over 3000 sets of high - grade plastic extrusion production lines and other complete sets of equipment, which are sold in more than 120 countries and regions.
Certification
FAQ
Q1. How long is the delivery time?
A1. Usually it takes about 1-4 months upon receipt of order advance payment.
Q2. Installation and stuff training available from you?
A2. Yes, we have rich engineers around the world which can send to your factory and train your workers. Also we can online guide your members.
Q3. How long is the guarantee?
A3. We offer you high quality machines with 12 months guarantee and reply you as soon as possible within 6 hours.
Q4. What is your production capacity?
A4. We produce more than 3000 advanced extrusion lines every year world wide.
Q5. How does your factory do regarding quality control?
A5. We have passed the IS09001:2015 Quality Management System and CE certificate and we have a special QC department in charge of products' quality. If you also need other certificates, we also can help to apply.
