Pipe Crusher
Description
Pipe Crusher Performance ＆ Advantages
DYPS Series Light Crusher
DYPS series light crushers have beautiful exterior design and high-quality steel structure welding. The rotor uses the latest V-shaped cutting technology to send the crushed material to the central, which not only avoids the material impacting on the sidewall, but also makes the sidepiece wearable, and reduces dust producing. The main shaft is made of high-quality material. We can also provide crushing auxiliary devices according to customer's requirements, such as suction unit collector, feeding conveyor belt and metal separator etc.
|
Model |
Feed Mouth Size (mm) |
Main Motor Power (kw) |
Rotor Blade (pcs.) |
Fixed Blade (pcs.) |
Rotor Dia. (mm) |
Output (kg/h) |
|
DYPS-560 |
560×400 |
15 |
6 |
2 |
Φ400 |
200 |
|
DYPS-700 |
700×700 |
22-37 |
6/10 |
4 |
Φ500 |
400 |
|
DYPS-800 |
800×800 |
45-55 |
6/10 |
4 |
Φ600 |
600 |
DYPS-Z Series Heavy Crusher
DYPS-Z series heavy crushers are designed specially for the recycling material which is not easy to be crushed and thickness 3-30mm.
Main shaft: The main shaft is processed with high quality steel after verifying the balance. Good toughness, stable working state, low shaking are the main features. The rotor with new "V" shape cutting technology is composed of 3, 5, or 7 pieces of blades on the basis of different crushing material. This technology makes sure the blade can produce uniform granular with low energy and low noise.
|
Model |
Feed Mouth Size (mm) |
Main Motor Power (kw) |
Rotor Blade (pcs.) |
Fixed Blade (pcs.) |
Rotor Dia. (mm) |
Output (kg/h) |
|
DYPS-Z 1000 |
1000×1000 |
55-110 |
10/14 |
4/6 |
Φ700 |
800 |
|
DYPS-Z 1200 |
1200×1000 |
90-132 |
10/14/18 |
4/6 |
Φ800 |
1200 |
|
DYPS-Z 1500 |
1500×1000 |
110-200 |
14/18 |
4/6 |
Φ1000 |
2000 |
DYSSG Series Pipe Crusher and Shredder Unit
- DYSSG series single shaft shredders can be used for shredding PE, PP and PVC pipes with a diameter of 1600mm. Pipes with a length of 3-6M can be directly crushed without splitting. The rotation speed is stable. After being placed into the horizontal feeding trough, pipe can be pushed into the center of the by hydraulic propulsion as the feeding trough closed automatically. The shredded material is brought into the crusher by a conveyor for secondary crushing for the required broken granule size.
- The main advantage of the DYSSG series shredder system is that it saves a lot of segmentation labor and sawing waste, saves energy and reduces consumption. It is safe and efficient. The whole system is controlled by the PLC central control system.
|
Model |
Rotor Dia. (mm) |
Drive Power (kw) |
Shreddable Pipe Dia. Max. (mm) |
Output (kg/h) |
|
DYSSG-630 |
Φ848 |
2×30 |
630 |
800-1000 |
|
DYSSG-800 |
Φ1028 |
2×37 |
800 |
1000-1200 |
|
DYSSG-1000 |
Φ1258 |
2×45 |
1000 |
1200-1500 |
|
DYSSG-1200 |
Φ1478 |
2×55 |
1200 |
1500-2000 |
|
DYSSG-1600 |
4×Φ490 |
55×3+75 |
1600 |
1800-2500 |
|
DYSSG-2000 |
4×Φ620 |
90×3+110 |
2000 |
2200-2800 |
Why Choose JWELL?
With over 25 years of expertise in plastic extrusion, JWELL Machinery is one of the largest manufacturers of plastic pipe extrusion lines globally. We provide turnkey solutions, including R&D, manufacturing, installation, and 24/7 after-sales support across our multiple production bases. Our equipment is exported to over 120 countries and regions worldwide, trusted by leading manufacturers for its reliability and efficiency.
Certification
FAQ
Q: 1. What about the payment way?
A: 1. By TT, L/C at sight. 30% down payment should be paid after contract is valid, 70% balance should be paid before shipment.
Q: 2. Is Jwell Machinery a Manufacturer?
A: 2. Yes, We own 11 manufacturing bases and sales center in Shanghai , Suzhou ,Changzhou, Zhou Shan, FoShan, LiYang, TaiCang, Dongguan China. Jwell made the first Chinese screw and barrel in 1978 in brand name Jinhailuo.
Q: 3. What is your Minimum Order Quantity?
A: 3. One. We provide both customized extrusion lines and technical solutions. Welcome contact with us for technical
innovation or improvements for your future purchasing plan.
Q: 4. How long is the guarantee?
A: 4. We offer you high quality machines with 12 months guarantee and reply you as soon as possible within 6 hours.
Q: 5. How does your factory do regarding quality control?
A: 5. We have passed the IS09001:2015 Quality Management System and CE certificate and we have a special QC department in charge of products' quality. If you also need other certificates, we also can help to apply.
Q: 6. What is your packaging?
A: 6. Standard packaging: The machine is anti-rust treated, plastic-film wrapped and then firmly fixed to a wooden bracket.
Q: 7. How can we check the machines before delivery?
A: 7. We can provide online checking when testing the machine on site. We will take and prepare detailed testing videos for your checking before the delivery. We accept third-party testing. Except above points, we will provide detailed testing report.
