Pipe Winder
Description
Performance ＆ Advantages
Pipe Winder Classification
Single-station
One reel - reel changes require a stop. Low cost, small footprint, ideal for low-volume, high-mix production.
Dual-station
Two switchable reels allow non-stop changeovers. Suited for high-volume production.
Semi-automatic
Basic winding and traversing only; reel change, cutting and unloading are manual. Low cost but quality can be inconsistent.
Fully automatic
PLC and touchscreen control, integrating automatic tension, traversing, reel change, packing and unloading. Consistent quality, minimal labour, perfect for high-speed, standardized production.
| Machine Type | Key Features | Roll Change Method | Labor Intensity | Production Efficiency | Equipment Cost |
| Single-station Semi-automatic | Simplest structure, lowest cost | Manual roll change with machine stop | High (full-time attendance required) | Low | ★☆☆☆☆ |
| Single-station Automatic | High automation, but roll change still requires machine stop | Automatic roll change with machine stop | Low (only unloading required) | Medium | ★★★☆☆ |
| Dual-station Semi-automatic | Enables continuous production, but roll change needs manual assistance | Manual-assisted roll change without machine stop | Medium | Medium-High | ★★★☆☆ |
| Dual-station Automatic | Full-process automation, non-stop continuous production | Fully automatic roll change without machine stop | Very Low (only routine inspection required) | Highest | ★★★★★ |
Pipe Winder Advantages
- Higher efficiency: the dual-station design enables nonstop auto reel change, keeping the line running at full speed.
- Better quality: precise servo tension and traverse control eliminate loose winding and scratches from manual handling, delivering neat, flawless rolls.
- Lower cost: automatic cutting and unloading cut labour costs and minimise material waste.
Company Profile
Jwell was founded in 1997, China Plastics Machinery Industry Association vice president unit, plastic extrusion equipment, chemical fiber spinning complete sets of equipment manufacturers. The production bases of Jwell company cover approximately 1,000,000 square meters and consist of 11 domestic factories and 3 foreign factories. The company has 26 professional subsidiaries and three heat treatment nitriding plants. It has an annual output of over 3000 sets of high - grade plastic extrusion production lines and other complete sets of equipment, which are sold in more than 120 countries and regions.
Certification
FAQ
Q: 1. What pipe materials are supported?
A: 1. JWELL pipe coilers are suitable for a wide range of flexible plastic pipes, including:
HDPE pipes
LDPE pipes
PPR pipes
PE-RT pipes
Drip irrigation pipes
Microduct pipes
Flexible conduit pipes
Multilayer plastic pipes
The winding system can be customized according to the material characteristics and coil specifications of different pipe products.
Q: 2. Can the coiler operate without stopping the extrusion line?
A: 2. Yes. JWELL's dual-station automatic coilers are specifically designed for continuous production. The automatic reel change function allows the winding process to switch between stations without interrupting the extrusion line, helping manufacturers maximize output and improve overall equipment utilization.
Q: 3. Can the machine be integrated with existing extrusion lines?
A: 3. Yes. The pipe coiler can be integrated with both new and existing extrusion lines. It can communicate with upstream equipment and be synchronized with haul-off units, cutting systems, and extrusion controls to achieve smooth and reliable operation.
Q: 4. Is automatic cutting included?
A:4. Yes, depending on the selected model and automation level. JWELL offers semi-automatic and fully automatic winding systems equipped with automatic pipe cutting and coil transfer functions. Fully automatic models can complete pipe cutting, reel change, and coil unloading with minimal operator intervention, helping reduce labor requirements and improve productivity.
